Avanti | Peanut Harvester/Collector

Avanti
Peanut Harvester/Collector

Avanti
Peanut Harvester/Collector

Avanti
Peanut Harvester/Collector

THE NEXT STEP IN GRAINS AND SEEDS HARVEST

Agricultural automation, increased harvesting performance and cleaning efficiency, excellence in grain and seed quality, operational versality MULTICROP® - Peanuts, BEANS, Soybeans and Corn

  • PREMIUM CAB: best cabin of the market, greater ergonomics, high visibility, lower noise, air conditioning.
  • DIGITAL MONITORING: AGC CAM monitor with indicators, greater harvesting management in real time, operational management in real time, management of operational information, maintenance and precision agriculture.
  • FANS: Best air flow and cleanness, less time and easier maintenance.
  • SOFT FLOW - AVANTI HARVESTING SYSTEM: better quality of the grains and seeds, greater processing capacity, MULTICROP configuration.
  • TRANSPORT SYSTEM: Greater agility on the logistics and transport, transport belt, less grain damage.
EXPAND IMAGE
SEE GALLERY

Know the Avanti
Peanut Harvester/Collector

WATCH VÍDEO

Technical Characteristics

Feeding System (Considered as feeder)

MODEL AVANTI
Type of supply system Chain + rubber talisks
Speed Variable
Reversng system Yes
Width 1772 mm (feeder)

Threshing System

MODEL AVANTI
Type Low impacte axial flow
Number of rotors 2
Lenght 4157 mm
Rotor Diameter 298 mm
Speed (rpm) Variable
It has a reversng system Yes
Type of concave Peanuts - Corn - Soybeans - Beans

Separation sieve - Vibrating sieve

MODEL AVANTI
Sieve area - vibrating 4m² per dieve - total 8m²
Lenght / vibrating 4157 mm
Width / vibrating 980 per sieve / total 1960 mm
Drilling Casquinho(Peanut) / Casquinho + Ø5 mm (grains)t

Suction Turbine

MODEL AVANTI
Turbine work rotation (rpm) Variable
Number of turbines  2 turbines
Diameter 680 mm

Flow Sieve

MODEL AVANTI
Main sieve useful area 0,8m² per sieve / total 1,6m²
Lenght 792 mm
Width 976 per sieve / total 1952 mm
Diameter of sieve holes (mm) 50x60 (peanuts) / Ø18 (corn) Ø14 e 8x30 (soybeans) / Ø18 e 10x30 (beans)

Cups Elevator

MODEL AVANTI
Grain elevators 2
Bucket quantity 42 per elevator
Rotation speed (rpm) Variable

Storage System

MODEL AVANTI
Capacity (L) 11.000 liters
Unloader length 7 meters
Unloading system Side discharge
Speed Variable

Motor

MODEL AVANTI
Brand / Model John Deere 6090Cl550
Number of cylinders 6
Nominal power 375 hp / 2200 rpm
Maximum Power 413 hp / 2000 rpm
Maximum Torque 1671 N.m / 1600 rpm

Transmission System

MODEL AVANTI
Number of gears 3 speed transmission powered by a hydrostatic engine
Speeds 3 gears, all with the options of reduced (turtle) and fast (hare)
Speeds range 0 - 35 km/h

Dimensions

MODEL AVANTI
Total length without platform 8.8800 mm
Total width without plataform 4.500 mm
Total height 5.000 mm
Weigth without platform 18.000 kg
